MU Simplex Connector

Request for Quote

SANWA offers a full range of MU Simplex Connectors, including single-mode, multi-mode, and APC type, each available for 0.9mm and 2.0mm boot connectors. These space-efficient connectors feature a pre-assembled format, making assembly implementation simple and also cost-efficient due to shortened production time.

Characteristics

  • IEC61754-7, TIA/EIA, GR-326-CORE compliant
  • RoHS and REACH compliant
  • UL94V-0 flammability grade
  • SM, MM, and APC types
  • Available for 0.9mm and 2.0mm boot connectors
  • Pre-assembled
  • Various colors of housing/boot options

Additional information

Ferrule ID

SM 125.5um, MM127um, APC 125.5um
Cable Size

900um, 2.0mm
Boot Color

White, Blue, Red, Yellow, Black, Beige, Green
